Specifications
Confirm model, interface type, rate, power, airflow and software version before ordering.
RUCKUS ICX 8200 8 25 GbE for or, PoE++ (802.3bt), VXLAN andH L2/L3,
This product category is a Ruckus switch designed for enterprise networks.
This product is a networking product designed for enterprise and data center networking.
This product category is a Ruckus switch designed for enterprise and data center networking. Key specifications include 1480 W.
This product is a networking product designed for enterprise and data center networking.
| RUCKUS ICX 8200-48ZP2-E2 | |
| Switching capacity (data rate, full duplex) | 334 Gbps |
| Forwarding capacity (data rate, full duplex) | 254 Mpps |
| 10/100/1000 Mbps RJ45 ports | 32 |
| 100/1000 Mbps/2.5 Gbps RJ45 downlinks (full duplex only) | 16 |
| 1/10 Gbps SFP/SFP+ uplinks | - |
| 1/10/25 Gbps SFP/SFP+/SFP28 uplinks | 4 |
| PoE/PoE+ 802.3at ports | 32 |
| Dual hot-swap power supplies and fan modules | yes |
| Max PoE Class 3 ports (15.4 W per port) | 48 |
| Max PoE+ Class 4 ports (30 W per port) | 24 (1 PSU) 48 (2 PSU) |
| Maximum PoE++ Class 6 ports (60 W per port) | 12 (1PSU) 16 (2 PSU) |
| Maximum PoE++ Class 8 Ports (90 W per port) | 8(1PSU) 16 (2PSU |
| Advanced IPv4/v6 Layer 3 (OSPF, VRRP, VRF, GRE, PIM, PBR) | With License |
| Aggregated stacking bandwidth (data rate, full duplex) | 1.2 Tbps |
| Stacking density (maximum switches in a stack) | 12 |
| Stacking ports (maximum ports usable for stacking) | Up to 4×25 GbE SFP28 |
| Maximum stacking distance (distance between stacked switches) | 10 km |
